一、Instrument Overview：
The KODIN 3A-EM series electromagnetic ultrasonic thickness gauge is a small-sized, coupling free, non-contact measuring instrument that can measure the thickness of various metals or magnetic materials.
This product is easy to carry, simple to measure, and comes with functions such as A-scan (waveform display). It is an electromagnetic ultrasonic thickness gauge that integrates multiple functions.
二、Technical Specifications：
(1) Testing materials: metal materials such as carbon steel, stainless steel, cast iron, aluminum, copper, gold, silver, nickel, etc;
(2) Detection range: 1.2-300mm (carbon steel), the maximum measurement range is affected by the properties of the tested material, sound attenuation coefficient, surface condition, and other conditions;
(3) Speed adjustment range: 1000~9999m/s;
(4) Indication accuracy: 0.01mm;
(5) Measurement error (H is the thickness value of the measured object): H<10mm, ± 0.05mm; H ≥ 10mm, ± (0.01+H/200) mm;
(6) Probe lifting range: maximum lifting distance of 3mm (normal temperature probe, actual lifting distance depends on material properties and temperature, etc.);
(7) Compatible probes: Room temperature probe (≤ 120 ℃, short-term measurement, 4Mhz);
(8) Probe excitation method: permanent magnet;
(9) Probe tilt angle: ≤± 25 °;
(10) Probe sound wave type: shear wave (transverse wave);
(11) Waveform display: Host (RF+, RF -); Flat panel (full wave, positive half wave, negative half wave, frequency wave);
(12) Detectable workpiece minimum diameter (curvature): 6mm;
(13) Storage capacity: divided into 200 groups, each with 30 measurement points, for a total of 6000 measurement points;
(14) Communication method: It can be connected to a tablet app through a WiFi hotspot;
(15) Host operating temperature: -10 ℃~50 ℃;
(16) Host storage temperature: 0~40 ℃;
(17) Power supply method: Equipped with a built-in lithium battery, it can provide approximately 5 hours of use for the instrument when fully charged;
(18) Dimensions: Length 205mm x Width 52mm x Thickness 32mm;
(19) Body weight: 500g (with ambient temperature probe).
三、Standard product packing list：
1. 1 3A-EM series host
2. 1 carbon steel test block
3. 1 stainless steel test block
4. 1 roll of anti-wear tape
5. 1 5V 1A charger
6. 1 copy of user manual
7. 1 copy of warranty card and certificate of conformity
8. 1 suitcase
-
